Friction losses of cemented unclassified iron tailings slurry based on full-scale pipe-loop test

Authors: Wu, AX; Ruan, ZE; Shao, YJ; Wang, JD; Yin, SH; Wang, SY; Li, CP

Open access courtesy of:

DOI https://doi.org/10.36487/ACG_rep/1910_44_Ruan

Cite As:
Wu, AX, Ruan, ZE, Shao, YJ, Wang, JD, Yin, SH, Wang, SY & Li, CP 2019, 'Friction losses of cemented unclassified iron tailings slurry based on full-scale pipe-loop test', in AJC Paterson, AB Fourie & D Reid (eds), Paste 2019: Proceedings of the 22nd International Conference on Paste, Thickened and Filtered Tailings, Australian Centre for Geomechanics, Perth, pp. 571-578, https://doi.org/10.36487/ACG_rep/1910_44_Ruan

Download citation as:   ris   bibtex   endnote   text   Zotero


Abstract:
Friction losses is a key parameter in the design of pipeline transportation in paste backfill. A full-scale pipeloop test was conducted in the JCHX Paste Backfilling laboratory to investigate the friction losses of cemented unclassified iron tailings slurry. Friction losses in upward sloping pipe, vertical downward pipe, vertical upward pipe, 90° long radius elbow, horizontal straight pipe and downward sloping pipe were tested simultaneously under different solid fractions. The results indicated that friction losses always increase with flow rate and solid fraction. Friction losses in the elbows are about 1.55–2.16 times that in the horizontal straight pipe, which is about 2.7–10.0 kPa·m-1. The pipe-loop test data can be used to analyse the rheological priorities of cemented unclassified tailings slurry. Based on the Buckingham rheological equation, an empirical formula for friction losses was established and applied to a pipe with the optimal diameter of DN 150 mm. It can be concluded that the full-scale pipe-loop test is an effective way to investigate friction losses and the economics of design pipeline transportation.

Keywords: friction losses, unclassified tailings, pipe-loop test, pipeline transportation

References:
Hallbom, DJ 2008, Pipe Flow of Homogeneous Slurry, PhD thesis, The University of British Columbia, Vancouver.
Kaushal, DR, Thinglas, T, Tomita, Y, Kuchii, S & Tsukamoto, H 2012, ‘CFD modeling for pipeline flow of fine particles at high concentration’, International Journal of Multiphase Flow, vol. 43, pp. 85–100.
Kumar, N, Gopaliya, MK & Kaushal, DR 2018, ‘Experimental investigations and CFD modeling for flow of highly concentrated iron ore slurry through horizontal pipeline’, Particulate Science and Technology, pp. 1–19.
Paterson, AJC 2012, ‘Pipeline transport of high density slurries: a historical review of past mistakes, lessons learned and current technologies’, Mining Technology, vol. 121, no. 1, pp. 37–45.
Paterson, A & Goosen, P 2015, ‘High-concentration hydraulic transport systems’, in RJ Jewell & AB Fourie (eds), Paste and Thickened Tailings: A Guide, 3rd edn, Australian Centre for Geomechanics, Perth, pp. 171–190.
Wei, C, Wang, XM, Zhang, YH & Zhang, QL 2017, ‘Paste-like cemented backfilling technology and rheological characteristics analysis based on jigging sands’, Journal of Central South University, vol. 24, no. 1, pp. 155–167.
Wu, AX & Liu, XH 2014, ‘Resistance characteristics of structure fluid backfilling slurry in pipeline transport’, Journal of Central South University, vol. 45, no. 12, pp. 4325–4330 (in Chinese).
Wu, AX, Ruan, ZE, Wang, YM, Yin, SH, Wang, SY, Wang, Y & Wang, JD 2018, ‘Simulation of long-distance pipeline transportation properties of whole-tailings paste with high sliming’, Journal of Central South University, vol. 25, no. 1, pp. 141–150.
Wu, D, Yang, B & Liu, Y 2015, ‘Pressure drop in loop pipe flow of fresh cemented coal gangue–fly ash slurry: experiment and simulation’, Advanced Powder Technology, vol. 26, no. 3, pp. 920–927.
