Roofex® –Results of Laboratory Testing of a New Concept of Yieldable Tendon

Authors: Charette, F; Plouffe, M Download Paper

DOI https://doi.org/10.36487/ACG_repo/711_28

Cite As:
Charette, F & Plouffe, M 2007, 'Roofex® –Results of Laboratory Testing of a New Concept of Yieldable Tendon', in Y Potvin (ed.), Deep Mining 2007: Proceedings of the Fourth International Seminar on Deep and High Stress Mining, Australian Centre for Geomechanics, Perth, pp. 395-404, https://doi.org/10.36487/ACG_repo/711_28



Abstract:
To provide the mining and tunnelling industries with a rock reinforcement fixture that is better suited to mining with high stress conditions, Atlas Copco has developed a new rockbolt that can accommodate both very large displacements and high energy release in the rock mass. The design principles that guided the development of the rockbolt are presented and discussed. For one, the Roofex® was designed to offer accurate pre-set load-deformation behaviour. This first model or prototype is based on a 12.5 mm diameter steel bar because of borehole diameter limitations.
