Authors: Spottiswoode, SM; Linzer, LM; Majiet, S


Cite As:
Spottiswoode, SM, Linzer, LM & Majiet, S 2008, 'Energy and Stiffness of Mine Models and Seismicity', in Y Potvin, J Carter, A Dyskin & R Jeffrey (eds), Proceedings of the First Southern Hemisphere International Rock Mechanics Symposium, Australian Centre for Geomechanics, Perth, pp. 693-707.

Download citation as:   ris   bibtex   endnote   text   Zotero


Abstract:
We analysed seismicity in two deep gold mines in terms of strain energy release during mining. Mining took place with regularly-spaced dip pillars and backfill for regional support. The mines were chosen to represent mining of the Carbon Leader reef (CLR) and the Ventersdorp Contact reef (VCR). More than 500,000 m2 of reef were mined over several years and generated more than 10,000 events of magnitude greater than 0.0 in each case. Most seismicity was located close to faces that were actively mined, at least within the assumed location error of 50 m. Software was developed to associate seismic events with faces that were mined during the same month, or if not close to active faces, with stationary faces or abutments. Areas of mining that were active in each month and that were more than 100 m from any other active mining were grouped together to form over 300 discrete seismogenic regions, or polygons for each month of mining. Mining and seismicity data were cumulated in various ways including cumulating values for data sorted by increasing values of energy release rate (ERR) computed numerically and averaged over each polygon. The most obvious result was that cumulated seismicity was more clearly proportional to cumulated strain energy release than to cumulative area mined, supporting the use of minimisation of ERR as an effective rockburst control method when ERR is calculated from the ratio of strain energy release to area mined. The linear relationship between cumulated seismicity and cumulated strain energy was maintained even when the reef was assumed to yield at normal stress of 300 MPa and more. It was only when modelled pillar strength was reduced to 250 MPa or less at both mines, that the models released excessive strain energy release at high values of ERR. It is possible that the design criterion of 400 MPa for pillar strength applied on one mine was conservative. The role of geological structures on seismicity was not the focus of this paper as mining in the vicinity of these structures took place at all spans and therefore at all values of ERR. In a separate study we showed that geological structures contribute 50% or less of the total amount of seismicity. The apparent stress and the ratio of seismic moment derived from P-waves to that derived from S-waves were found to vary with ERR, with both decreasing with increasing ERR for data from mining of the CLR, while the apparent stress increased with increasing ERR for VCR mining, as expected for the generally increasing levels of stress ahead of the advancing faces. We suggest that the decrease in values for the CLR data might be attributable to a more extensive fracture zone resulting from bedding-plane slip than occurs around the VCR with its massive lava hangingwall. We propose a simple softening model to explain the CLR behaviour.

References:
Adams, G.R., Jager, A.J. and Roering, C. (1981) Investigation of rock fracture around deep-level gold mine stopes. Proc. 22nd US Symp. Rock Mech., pp. 213–218.
Boettcher, M.S., McGarr, A., Durrheim, R.J., Spottiswoode, S., Milev, A., Linzer, L., Johnston, M.J.S. and Sell, R.W. (2008) A broadband, wide dynamic range investigation of earthquakes in deep South African gold mines, abstract, Seismological Research Letters, Vol. 79, No. 2, p. 311.
Cook, N.G.W., Hoek, E., Pretorius, J.P.G., Ortlepp, W.D. and Salamon, M.D.G. (1966) Rock Mechanics applied to rockbursts. Journal of the South African Institute for Mining and Metallurgy, pp. 435–714.
Handley, M.F., De Lange, J.A.J., Essrich, F. and Banning, J.A. (2000) A review of Sequential Grid Mining method employed at Elandsrand Gold Mine. Journal of the South African Institute for Mining and Metallurgy, Vol. 100, No. 3, pp. 157–168.
Jager, A.J. and Ryder, J.A. (1999) A Handbook on Rock Engineering Practice for tabular hardrock mines. SIMRAC, Johannesburg.
Kgarume, T. and Spottiswoode, S.M. (2008) Temporal and special behaviour of mine aftershocks density and event rate, unpublished presentation at ISSI 2008 Symposium.
Klokow, J.W., Riemer, K.L. and Ferreira, R.I. (2003) An initial assessment of the closely spaced dip – pillar mining layout as practiced at Driefontein Gold Mine. ISRM 2003 Technology roadmap for rock mechanics, S.A. Inst. Min. Metall., pp. 655–633.
Malan, D.F., Napier, J.A.L. and Grave, M. (2003) Experiments on stope closure as a diagnostic measure of rock behaviour. ISRM 2003–Technology roadmap for rock mechanics, South African Institute of Mining and Metallurgy, pp. 795–801.
McGarr, A. and Wiebols, G.A. (1977) Influence of Mine Geometry and closure volume on Seismicity in deep level mine. Int. J. Rock Mech. Min. Sci. and Geomech. Abstr., Vol. 14, pp. 139–145.
McGarr, A., Spottiswoode, S.M., Gay, N.C. and Ortlepp, W.D. (1979) Observations relevant to seismic driving stress, stress drop, and efficiency. J. Geophys. Res., 84, pp. 2251–2261.
McGill, R.B. (2005) Strategies to manage seismicity in a deep VCR environment on Mponeng, 6th Intl Symposium on Rockbursts and Seismicity in mines, Perth, Australia, pp. 419–424.
Milev, A. and Spottiswoode, S.M. (1997) Integrated seismicity around deep-level stopes in South Africa. Int. J. Rock Mech. and Min. Sci., Vol. 34, No. 199, pp. 3–4.
Napier, J.A.L. (1991) Energy changes in a rock mass containing multiple discontinuities. J. S. Afr. Inst. Min. Metall., Vol. 91, pp. 145–157.
Ortlepp, W.D. (1997) Rock Fracture and Rockbursts: an illustrative study. Monograph series M9. South African Inst. Min. Metall., 220 p.
Ryder, J.A. and Jager, A.J. (editors) (2002) A textbook on Rock Mechanics for tabular hard rock mines. 1st Edition, SIMRAC, Johannesburg, p. 233; p. 239.
Share, P-E. (2007) Dynamic and Quasi-static Deformations of the Rocks Derived from Underground Seismic and Tilt Data, Geophysics Honours Project, University of Witwatersrand.
Spottiswoode, S.M. (1980) Thesis: Source Mechanism Studies on Witwatersrand Seismic Events, unpublished PhD thesis, University of the Witwatersrand.
Spottiswoode, S.M. (1997) Energy Release rate with limits to on-reef stress Proc. 1st Southern African Rock Engineering Symposium, R.G. Gurtunca and T.O. Hagan (editors), SANGORM, pp. 252–258.
Spottiswoode, S.M. (2001) Keynote address: Synthetic seismicity mimics observed seismicity in deep tabular mines. 5th Intl Symposium on Rockbursts and Seismicity in mines, S.A. Inst. Min. Metall., pp. 371–378.
Spottiswoode, S.M. (2005) Mine Layout Design and Medium-term Prediction of Seismicity, 5th Intl Symposium on Rockbursts and Seismicity in Mines, Perth, Australia, pp. 211–218.
Spottiswoode, S.M., Scheepers, J. and Ledwaba, L. (2006) Pillar seismicity in the Bushveld Complex, in Facing the Challenges, South African National Institute of Rock Engineering, pp. 140–158.
Toper, A.Z. (2007) Destressing/Preconditioning to Control Rockbursts in South African Deep-Level Gold Mines, in Challenges in Deep and High Stress Mining, Australian Centre of Geomechanics, pp. 503–515.
van Antwerpen, H.E.F. and Spengler, M.G. (1982) The effect of mining-related seismicity on excavations at East Rand Propriety Mines, Limited. 1st Intl. Symposium on Rockbursts and Seismicity in Mines, Johannesburg, S. Afr. Inst. of Min. Metall., pp. 29–37.
van Aswegen, G. (2005) Routine seismic hazard assessment in South African mines. 6th Intl Symposium on Rockbursts and Seismicity in Mines, Perth, Australia, pp. 437–444.
