Authors: Paulka, SM; Staggs, D; Ralls, G; Sivarudrappa, K; Sigda, J

Open access courtesy of:


Cite As:
Paulka, SM, Staggs, D, Ralls, G, Sivarudrappa, K & Sigda, J 2023, 'Transforming Ranger’s TSF to a process water storage facility', in B Abbasi, J Parshley, A Fourie & M Tibbett (eds), Mine Closure 2023: Proceedings of the 16th International Conference on Mine Closure, Australian Centre for Geomechanics, Perth,

Download citation as:   ris   bibtex   endnote   text   Zotero

The former Ranger uranium mine above-ground tailings storage facility (TSF) is a recent addition to an ancient Northern Australian landscape. The Ranger Project Area is surrounded by, but separate from, the dual World Heritage listed Kakadu National Park – recognised for its cultural and natural values. The responsible and safe closure of the TSF is essential with the recent cessation of uranium mining activities. As part of the Ranger Rehabilitation Project, Energy Resources of Australia (ERA) recently converted the TSF into a process water storage facility. The newly named Ranger Water Dam (RWD) will continue to store process water until treatment is completed, following which any residual contaminated material will be managed, and the facility will be deconstructed and revegetated. This paper reviews several of the geotechnical, hydrogeological, and other challenges associated with tailings removal from the TSF and its conversion to the RWD. ERA removed and transferred 27 Mt of uranium tailings to a nearby open pit for permanent storage. The transfer operation was unique and required specialist geotechnical input to plan and coordinate the tailings removal, including during dredging operations, final pump-out of contained process water, and mechanical removal of remnant tailings solids from the TSF. Methods employed by the mine’s consultant dam engineer included a weekly remote review of site monitoring data, frequent site visits at the height of a global pandemic, and office-based computational assessments described in the paper to support activities. All this work successfully met stringent stakeholder requirements and ongoing closure objectives. The original Ranger TSF design and construction was both a tailings and water storage facility; however, prior to conversion to the RWD a hydrogeological assessment was undertaken to quantify how the loading of groundwater solutes to creeks would change. The results showed that storage of process water would not impact the surrounding environment allowing stakeholders to approve the change in use of the facility.

Keywords: tailings storage facility, water storage facility, closure, geotechnical, hydrogeology

Australian National Committee on Large Dams 2019, ‘Guidelines on Tailings Dam: Planning, Design, Construction, Operation and Closure’, Revision 1, July 2019.
Coffey Services Australia Pty Ltd 2017, ‘Ranger Mine Project, Eastern Perimeter Embankment Notching and MOL Adjustment Design Report’, 20 December 2017 (unpublished).
Coffey Services Australia Pty Ltd 2018, ‘2018 TSF Rapid Drawdown Assessment, Ranger Mine TSF’, 5 November 2018 (unpublished).
Coffey Services Australia Pty Ltd 2019, ‘2019 TSF Rapid Drawdown Assessment, Ranger Mine TSF’, 9 September 2019 (unpublished).
Coffey Services Australia Pty Ltd 2019, ‘TSF Crest Access – Wall Cleaning, Ranger Mine’, 10 December 2019.
Coffey Services Australia Pty Ltd 2020, ‘TSF Floor Cleanup – Southeast and West Access, Ranger Mine’, 15 April 2020 (unpublished).
Coffey Services Australia Pty Ltd 2021, ‘Rapid Drawdown Monitoring Report’, 26 April 2021 (unpublished).
Coffey Services Australia Pty Ltd 2020, ‘TSF Ramp Stability – Hydromining, Ranger Mine’, 12 November 2020 (unpublished).
Energy Resources of Australia Ltd, ‘Tailings Quantity Reconciliation’, 11 April 2022 (unpublished).
INTERA (2022), Technical Memorandum, Groundwater Assessment for Transitioning of the Tailings Storage Facility into a Water Storage Facility, 20 January 2022 (unpublished)
Rio Tinto 2021, ‘Group procedure – D5 – Management of tailings and water storage facilities v1.2’.
Tetra Tech Coffey Pty Ltd 2021, ‘Ranger Mine – TSF North-East Ramp – CAT 785 Truck Access’, 1 July 2021 (unpublished).
Tetra Tech Coffey Pty Ltd 2021, ‘Ranger Mine – TSF NE Access Ramp Construction Compliance’, 30 August 2021 (unpublished).
Tetra Tech Coffey Pty Ltd 2021, ‘Ranger Water Dam – Energy Dissipator for Pipe Outlet’, 16 November 2021 (unpublished).
Tetra Tech Coffey Pty Ltd 2021, ‘Ranger Water Dam (formerly TSF) OMM, Operations and Maintenance Manual Update’, 24 December 2021 (unpublished).
Tetra Tech Coffey Pty Ltd 2022, ‘Ranger Mine – Water Dam (former TSF) Inspection, 25 November 2021’, 24 January 2022 (unpublished).
Tetra Tech Coffey Pty Ltd 2022, ‘Ranger Water Dam, Annual Inspection 2022’, 28 September 2022 (unpublished).
